LEDIA LF

Perfectly integrated – for impressive lighting effects

The LEDIA LF illuminating tile offers a diverse range of possibilities when it comes to creative lighting effects. The LEDIA LF is available in various sizes and thus can be employed in a variety of ways. The illuminating tile provides colour-intensive and atmospheric lighting effects and is suitable for in-ground outdoor as well as underwater installation.

Related Products

LEDIA LF

LED lighting effects
(selected series)

LEDIA LL

LED lighting effects

Technical details

Square luminaire body made of stainless steel. Luminaire enclosure made of single-pane tempered safety glass with non-slip printing. Mounting frame made of stainless steel for installation height 120mm. Four sizes (95, 195, 295, 395mm). Maintenance-free. Power supply is provided by an external power supply unit for mounting in the on-site sub-distribution. Protection rating III. Do not allow chemicals or other corrosive materials to come in contact with the luminaire.

LEDIA LF OD:
Can be rolled over up to a weight of 1.5t or 5.0t. LED fittings: Effect light (EL) or colour change (RGB) up to approx. 25W. Cable on site.

LEDIA LF UW:
LED fittings: Effect light (EL) up to approx. 13W. For use under water, the light tile is additionally moulded inside. Illuminating tile with pre-wired connection cable for contacting outside the wet area. Please specify cable length when ordering.

LED Lifetime
L80 B10 / 85.000h - TA <= 25°C
L70 B10 / 50.000h - TA >25 - <=50°C
Ingress protection
IP67
IK-Value
IK08

You will find further technical data if you have specified a variant.

Choose variant
